🔥 M4 Crushes M2: Apple Silicon VLM Benchmark Shows Up to 5× Speed Boost!

🚀 Image Captioning and Visual Understanding with VLM

Ever wondered how fast cutting-edge vision-language models can run on Apple Silicon? This script puts Moondream2 to the test with a wide range of visual understanding tasks:

  • 📝 Image Captioning — short, detailed, streamed, and non-streamed
  • ❓ Visual Queries — ask natural language questions about what’s inside the image
  • 🎯 Object Detection — find all instances of a given object
  • 📍 Pointing — locate objects in the image by name

It also benchmarks runtime performance of these tasks to compare different Apple Silicon chips (M2 vs M4) using the Metal Performance Shaders (MPS) backend.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
import time
from transformers import AutoModelForCausalLM
from PIL import Image

# Load the model
model = AutoModelForCausalLM.from_pretrained(
    "vikhyatk/moondream2",
    revision="2025-06-21",
    trust_remote_code=True,
    device_map={"": "mps"}  # Change to "mps" on Apple Silicon if needed
)

# Load the image
image_path = "/tmp/img.png"
image = Image.open(image_path).convert("RGB")

# Track total runtime
global_start = time.time()

# --- Captioning: Short ---
print("Short caption:")
t0 = time.time()
print(model.caption(image, length="short")["caption"])
print(f"[Short caption runtime: {time.time() - t0:.3f} sec]\n")

# --- Captioning: Normal (streamed with benchmarking) ---
print("Normal caption (streamed with timing):")
t0 = time.time()

stream = model.caption(image, length="normal", stream=True)["caption"]

latencies = []
start_time = time.time()
first_token_time = None

for i, token in enumerate(stream):
    now = time.time()
    if i == 0:
        first_token_time = now - start_time
    else:
        latencies.append(now - prev_time)
    prev_time = now

    print(token, end="", flush=True)

total_time = time.time() - start_time
avg_latency = sum(latencies) / len(latencies) if latencies else 0.0

print("\n\n--- Benchmark Results ---")
print(f"First token latency: {first_token_time:.3f} sec")
print(f"Average token latency: {avg_latency:.3f} sec")
print(f"Total generation time: {total_time:.3f} sec")
print(f"[Normal caption runtime: {time.time() - t0:.3f} sec]\n")

# --- Final Caption (non-streaming version) ---
t0 = time.time()
final_caption = model.caption(image, length="normal")["caption"]
print("Full caption (non-streamed):")
print(final_caption)
print(f"[Final caption runtime: {time.time() - t0:.3f} sec]\n")

# --- Visual Querying ---
print("Visual query: 'How many people are in the image?'")
t0 = time.time()
print(model.query(image, "How many people are in the image?")["answer"])
print(f"[Visual query runtime: {time.time() - t0:.3f} sec]\n")

# --- Object Detection ---
print("Object detection: 'face'")
t0 = time.time()
objects = model.detect(image, "face")["objects"]
print(f"Found {len(objects)} face(s)")
print(f"[Object detection runtime: {time.time() - t0:.3f} sec]\n")

# --- Pointing ---
print("Pointing: 'person'")
t0 = time.time()
points = model.point(image, "person")["points"]
print(f"Found {len(points)} person(s)")
print(f"[Pointing runtime: {time.time() - t0:.3f} sec]\n")

# --- Total Runtime ---
global_end = time.time()
print(f"=== Total end-to-end runtime: {global_end - global_start:.3f} sec ===")

Code Overview

  1. Load Model & Image

    • Loads the vikhyatk/moondream2 model with custom methods (caption, query, detect, point).
    • Opens a test image (/tmp/img.jpg) for processing.

  2. Captioning

    • Generates a short caption (one sentence).

    • Generates a normal caption:

      • In streaming mode, printing tokens as they arrive while measuring latency.
      • In non-streaming mode, returning the full caption at once.

  3. Visual Query

    • Answers natural-language questions about the image, e.g. “How many people are in the image?”

  4. Object Detection

    • Detects specified objects, e.g. “face”.

  5. Pointing

    • Finds spatial locations of objects, e.g. “person”.

  6. Benchmarking

    • Tracks runtime for each task.
    • Reports first token latency, average token latency, total generation time, and end-to-end runtime.

Results: M2 vs M4 (MPS Device)

We going to compare with this two image:

  • Little snowman
  • The public speech

Little Showman

Task M2 Runtime (s) M4 Runtime (s) Speedup (≈)
Short caption 13.37 4.44 3× faster
Normal caption (stream) 29.45 5.84 5× faster
Full caption (non-stream) 21.45 5.77 4× faster
Visual query 15.19 3.58 4× faster
Object detection 13.21 3.38 4× faster
Pointing 12.67 3.36 4× faster
Total runtime 105.34 26.36 ~4× faster

Public speech

Task M2 Runtime (s) M4 Runtime (s) Speedup
Short Caption 13.2 4.3 ~3×
Normal Caption (full) 20.0 6.8 ~3×
Visual Query 13.0 3.6 ~3.5×
Object Detection 12.9 3.5 ~3.5×
Pointing 14.9 3.8 ~4×
Total Runtime 95.3 28.9 ~3.3×

Key Takeaways

  • M4 dramatically outperforms M2 across all tasks, often by a factor of 3–5×.
  • First token latency (important for streaming applications) is much lower on M4 (0.08s vs 0.16s).
  • Average token latency improves significantly (0.043s vs 0.214s).
  • This makes M4 much better suited for interactive multimodal applications like real-time captioning, chat, or object recognition.

Example Output (Short Caption)

M2 & M4 produced nearly identical captions, but M4 was ~3× faster.

1
2
Short caption:
A white snowman figurine with green scarf and black band around neck sits on a red and black checkered base, surrounded by winter-themed items on a white surface.

How to Run

1
2
pip install transformers pillow
python script.py

Replace device_map={"": "cuda"} with "mps" for Apple Silicon.
Update image_path to your own test image.
